Hunter X2-401E Controller WIFI Compatible 4 Station WiFi Ready
Features
- Plug-less controller hardwired in by installers/contractors
- Number of stations – 4
- Backlit display provides optimal visibility in any light
- Hide Programs option shows 1 program and 1 start time for simplification
- During the off-season, suspend irrigation for up to 99 days
- 3 flexible programs with 4 start times and up to 6 hours run time VS Standard ABC Programming when used with the X2 WAND for 3 programs, 6 start times and run times up to 24 hours
- Compatibility with Amazon Alexa™ and Control4® home automation
Key Benefits
| Easy Retrieve™ Memory | Backs up the full irrigation schedule – Controller scheduling and setup information are stored in backup memory. Restore the saved watering schedule at any time or set the controller back to its initial settings if tampered with or at the beginning of a new season. |
| Programmable Rain Delay | Prevents watering during an extended period of inclement weather by enabling the user to specify the number of days for the controller to be kept in OFF mode before returning automatically to scheduled irrigation. The number of days before watering resumes is displayed on the controller. Irrigation restarts automatically without having to return to the controller. |
| Quick Check™ | Field wiring issues are easy to assess with the push of a button. When a field wiring short is detected on a particular station number, an ERR message is displayed. |
| Automatic Short Circuit Protection | Automatically detects electrical faults which are typically caused by wiring issues. Only the affected stations are skipped allowing all other stations to function normally. No fuses are blown or internal circuit breakers tripped, so complete irrigation system shutdown is avoided. Short-circuit protection detects wiring faults and skips the station without system damage. |
| Station Delay | Program a delay between stations as the controller advances between them. Ranges from a few-second delay (giving additional time for slow-closing valves) to a much longer time period (allowing pressure tanks recharge time). |
| Seasonal Adjustment | Adjust irrigation run times based on seasonal weather by setting the percentage scale without changing run times. During peak season, set the seasonal adjustment to 100% and lower this percentage if weather conditions mean plants require less water. |
| Cycle & Soak | Allows the operator to specify a max cycle time per station (hours, minutes or seconds) and a minimum soak time. This prevents runoff from slopes or saturated soil. Cycle and Soak prevent water waste and runoff in areas with elevation changes or tight soils. |
Specifications
- Transformer input: 230 VAC
- Transformer output (24 VAC): 1 A
- Station output (24 VAC): 0.56 A
- P/MV output (24 VAC): 0.28 A
- Sensor inputs: 1
- Approvals (controller): Plastic IP44, UL, cUL, FCC, CE, RCM
- Approvals (module): Wi-Fi 2.4 gHz b/g/n, Bluetooth 5.0, UI, cUL, FCC, CE, RCM
- Warranty period: 2 years
Dimensions
- Height: 23cm
- Width: 19cm
- Depth: 10cm
X2™ WITH WAND – watch the video
This online-capable controller offers rapid schedule programming and advanced water-saving features.
