The highly durable PGJ offers all the benefits of a large rotor in a compact, spray-sized package, with water-efficient nozzles and easy arc adjustment.

PGJ-04
Overall height: 18 cm
Pop-up height: 10 cm
Exposed diameter: 3 cm
Inlet size: 1⁄2″

• OPERATING SPECIFICATIONS
• Nozzle choices: 8
• Radius: 4.0 to 10.7 m
• Flow: 0.08 to 1.0 m3/hr; 1.4 to 16.7 l/min CHARTS
• Recommended pressure range: 1.7 to 3.8 bar; 170 to 380 kPa
• Operating pressure range: 1.4 to 7.0 bar; 140 to 700 kPa
• Precipitation rate: 15 mm/hr approximately
• Nozzle trajectory: 15° approximately
• Warranty period: 2 years

KEY BENEFITS

• Headed and slotted setscrew allows radius adjustment with a Hunter Wrench
or flat-blade screwdriver
• Adjustable arc from 40° to 360° to keep water in the appropriate areas
• Standard factory-installed 2.0 nozzle speeds installation
• QuickCheckTM Arc Mechanism for fast arc adjustment

GTIN: 40611698139644
